| No. | Category | Item | Specifications |
| 1 | System parameter | Container size ( L × W × H) | 6058mm×2438mm×2896mm |
| 2 | Rated Capacity | 3858kWh | |
| 3 | Maximum cycle efficiency | > 89 % | |
| 5 | Protection level | I P54 | |
| 6 | Auxiliary power supply | Self-powered /externally powered | |
| 7 | Working humidity range | ≤95 % | |
| 8 | Working temperature range | -20ºC~55ºC ( > 45ºC derating ) | |
| 9 | Maximum working altitude | 1500m | |
| 10 | Cooling method | Smart liquid cooling | |
| 11 | Fire extinguishing configuration | Aerosol fire protection, temperature detection, smoke detection | |
| 12 | Communication | RS485/CAN | |
| 13 | Communication protocol | Modbus rtu /CAN2.0 | |
| 14 | Weight | ≤ 36T | |
| 15 | DC parameter | Maximum DC voltage | 1382.4V |
| 16 | Minimum DC voltage | 1036.8V | |
| 17 | DC side rated current | 1570A | |
| 18 | DC side maximum current | 1865A |
| NO. | Item | Product Specification | Condition |
| 1 | Cell capacity | 314Ah | 25±2ºC 0.5C constant current charge to 3.65V, then constant voltage 3.65V charge till charged current declines to ≤ 0.05C |
| 2 | Working voltage | 2.5~3.65V @0ºC<T<55ºC 2.0V~3.65V@-20ºC<T≤0ºC | NA |
| 3 | Battery AC internal resistance | ≤0.30mΩ | AC1kHz |
| 4 | Working temperature (charging) | 0~55ºC | NA |
| 5 | Working temperature (discharging) | -20~55ºC | NA |
| 6 | Battery weight | 5.8±0.3kg | NA |
| 7 | Standard discharging power | 502.4W | 25±2ºC |
| 8 | Maximum continuous discharge power | 502.4W | 25±2ºC, SOC≥20% |
| 9 | Cell size | 174.1+1.0 /-2.0×7 2+3.0 /-1.0× 207.2±1 mm | NA |
