Place of Origin:
China
Brand Name:
Soundon
Certification:
CE,ROHS,MSDS,CB,UL
Model Number:
EV-014-36.5V/128Ah
|
Capacity
|
128Ah ,0.5 C discharging(25±2℃) | |
|
Minimum Capacity
|
128Ah ,0.5 C discharging(25±2℃) | |
| Nominal Voltage | 29.2V | |
|
Charge Ending Voltage |
33.6V | |
|
Discharge Ending Voltage |
0℃≤T(Temperature)≤55℃ 0℃≤T≤55℃ |
30V |
|
-20℃≤T(Temperature)≤0℃ -20℃≤T≤0℃ |
24V | |
|
Standard Charging Method |
25±2℃ 0.5C constant current charge to 33.6V, then constant voltage 33.6V charge till charged current declines to ≤ 0.05C | |
|
Max. Constant Charging Current |
1C (15℃～45℃) | |
|
Max. Pulse Charging Current |
1.5C (15℃～45℃)≤30S | |
|
Standard Discharging Current |
25±2℃ 0.5C constant current discharge to 48.0V |
|
|
Max. Constant Discharging Current
|
1C | |
|
Max. Pulse Discharging Current |
3C (15℃～45℃)≤30S | |
|
Operating environment |
Charging:-10℃~55℃, max.90%RH Discharging: -20℃~55℃, max.90%RH |
|
|
Weight |
26kg | |
|
Energy Density |
175 Wh/kg | |
Battery cell sepcificaiton :
| Capacity | 32Ah |
| Voltage | 3.6V |
| Charge cut-off voltage | 4.20V±0.03V |
| Impedance | ≤ 2.5 mΩ |
| Standard charge and discharge current | 0.5C |
| max constant charge and discharge current | 1C |
| mas pluse charging current | 1.5C |
| mas pluse discharging current | 3C |
| Operating temperature | Charging :-10~45℃ |
| Discharging :-20~55℃ | |
| Dimension | 11.5*126*216mm |
Superiority:
Using high energy density NCM materials up to 220wh/kg .
Battery cell is special design for electric vehicle which adopt the VDA standard size to match any model battery pack
Battery cell can configurate to any battery module can suit for car batteries,like below similar module:36.5V128Ah ,43.8v128Ah, 51.1V128AH ,58.4V64Ah
Passed the international certificate :UN38.3,MSDS,CE
Battery package are comply with international export transpotation rules UN38.3 and dangerous package certificate.
| Battery cell MODE | SEPNi11217127P | ||||
| Battery cell capacity Ah | 32Ah | ||||
| Configuration | 4P8S | 4P10S | 4P12S | 4P14S | 2P16S |
| Dimension mm (H*W*T) |
437*227*149 | 523*227*149 | 618*227*149 | 737*227*149 | 437*227*149 |
| Module Rated Capacity Ah/Wh | 128AH | 128AH | 128AH | 128 | 64 |
| Module Rated Voltage V | 29.2V | 36.5V | 43.8V | 51.1V | 58.4V |
| Module Weight Kg | 22kg | 26.6kg | 31.9kg | 37.5Kg | 22Kg |
| Module Weight Wh/Kg | 170 | 175.6 | 175.7 | 174 | 170 |
Battery module production line :
